Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable De
Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
Description of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
Sensepoint XCD RFD (Remote Flammable Detector) has been specifically designed for use with remotely mounted flammable gas sensors.
This configuration is ideal for applications where the sensor is required to be mounted remotely from the transmitter in areas where temperatures are well above ambient (up to 150°C/302°F), or that are difficult to access. The transmitter can be mounted at a suitable location away from this area where it is easy to access, view its display and interact with via the user interface.
Overview of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
The Sensepoint XCD Remote Flammable Detector (RFD) can be used with Sensepoint XCD remote flammable sensors (Catalytic and
IR), or with the Sensepoint range of flammable gas detectors. The sensors can be directly mounted to the M25 entry at the bottom of the transmitter, or remotely mounted to suitable junction boxes or duct mounting assemblies.
Sensepoint flammable detectors are available in both standard and high temperature versions.
Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
Sensepoint XCD RFD is suitable for use with several Honeywell Analytics’ sensors; the Sensepoint XCD catalytic bead and infrared type plug-in sensors and the Sensepoint standard and high temperature sensors.These sensors can be mounted up to 30 metres (100 feet) away from the transmitter thereby accommodating even the most remote and inaccessible applications.
The gas range is user adjustable at the transmitter from 0-100%LEL down to 0-20%LEL. The 0-20%LEL range is particularly suited for use with the Sensepoint high temperature sensors that have thermally matched beads providing optimum accuracy and stability allowing alarm set points as low as 5%LEL.
The transmitter’s tri-colour backlit LCD clearly indicates the unit’s status at a glance, even from a distance. A steady green backlight indicates normal operation, flashing yellow indicates fault and flashing red indicates an alarm.
Outputs include 2 programmable alarm relays, 1 programmable fault relay as well as 4-20mA output (sink or source selectable).
The range, relay operation, alarm set points and electronic tag number of the detector can be adjusted using the transmitter’s LCD and the non-intrusive magnetic switches.Outputs are automatically inhibited during adjustment thereby reducing the risk of false alarm at the control panel during maintenance
Applications of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
• Compatible with high temperature sensors for use in and around Gas Turbine Enclosures and solvent based printing and coating drying ovens
• Compliant with the requirements of HSE guidance note PM84
• Transmitter can be mounted in easy to access area even if sensor is in a hard to access or restricted access area
• Sensor can be mounted up to 30 metres (100 feet) from transmitter
• Standard temperature catalytic and infrared sensor types also available
Reliable detection of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
• Compatible with Honeywell Analytics’ proven catalytic bead flammable gas sensors
• High temperature gas sensors have thermally matched beads for highest accuracy and stability enabling low alarm levels
• Gas sensors use long life, poison resistant beads as standard, reducing ongoing cost of ownership
Easy to Use of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
• Easy to read tri-colour backlit display with digits,bar graph and icons
• Fully configurable via non-intrusive magnetic switches
• Selectable sink or source 4-20mA output
• Auto-inhibit during maintenance prevents false alarms
Cost Effective of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
• Sensepoint XCD common transmitter platform
• Reduces training costs
• Reduced spares and stock costs
• Non-intrusive, one-man operation reduces cost of maintenance
• Optional Sensepoint XCD plug-in sensor reduces maintenance time further
ACCESSORIES of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
Sensepoint XCD Duct mounting kit
SPXCDDMK
Duct mounting kit
Sensepoint XCD Mounting bracket
SPXCDMTBR
Mounting bracket (inc. bolts, nuts, brackets)
Sensepoint XCD Sunshade / Deluge Protection
SPXCDSDP
Sunshade / Deluge Protection
Sensepoint XCD RFD Transmitter of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDASMRFD ATEX/IECEX & AP approved SP XCD RFD Transmitter with 316SS
SPXCDALMRFD ATEX/IECEX & AP approved SP XCD RFD Transmitter with LM25
Sensepoint Flammable - High Temperature (0-20%LEL or 0-100%LEL +150°C)
2106B2310 Sensepoint HT Flammable Sensor (ATEX) M20
2106B2311 Sensepoint HT Flammable Sensor (ATEX) M25
2106B2312 Sensepoint HT Flammable Sensor (ATEX) 3/4 NPT
Sensepoint Flammable (0-100%LEL +80°C)
2106B1200 Sensepoint 0-100% LEL Flam. Sensor M20
2106B1201 Sensepoint 0-100% LEL Flam. Sensor M25
2106B1202 Sensepoint 0-100% LEL Flam. Sensor M26
2106B1204 Sensepoint 0-100% LEL Flam. Sensor 3/4NPT
Sensepoint XCD Remote Flammable Sensor (XCD Sensor Cartridge + Socket Housing)
SPXCDXSRFXSS Sensepoint XCD RFD remote plug-in sensor and socket, flammable CAT 0-100%LEL (20,0 to 100.0%LEL)*
SPXCDXSRRXSS Sensepoint XCD RFD remote plug-in sensor and socket, Methane IR 0-100%LEL (20,0 to 100.0%LEL)
SPXCDXSRPXSS Sensepoint XCD RFD remote plug-in sensor and socket, Propane IR 0-100%LEL (20,0 to 100.0%LEL)*
SPXCDXSRB1SS Sensepoint XCD RFD remote plug-in sensor and socket, Carbon Dioxide IR 0-2.00%VOL only*
Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
Accessories
00780-A-0100 Term Hsg - Bartec DE1155 With Continuity Plate 1 x 25mm - 3 x 20mm Entries - ATEX Approved
2052D0001 High temperature Exe junction box. ATEX approved. 3 x M20 Entries
90053-A-7041 High temperature single duct mounting assembly for use with FEEL Range 2000 junction box (P/N 2052D0001) - for use with European Sensepoint type detectors
S3KCAL Calibration cup
SPXCDCC Collecting cone for use with lighter than air gases
SPXCDDMK Duct mounting kit
SPXCDHMRTEN Hard copy manual in English
SPXCDMTBR Mounting bracket (inc. bolts, nuts, brackets)
SPXCDSDP Sunshade/deluge protection
SPXCDWP XCD Weather proof cap
Spare XCD Plug in sensor cartridges
SPXCDXSFXSS Flammable CAT 0-100%LEL (20 to 100%LEL, 10%LEL)*
SPXCDXSRXSS Methane IR 0-100%LEL (20 to 100%LEL, 10%LEL)
SPXCDXSPXSS Propane IR 0-100%LEL (20 to 100%LEL, 10%LEL)*
SPXCDXSB1SS Carbon Dioxide IR 0-2.00%VOL only*
Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
ACCESSORIES
Sensepoint XCD Duct mounting kit
SPXCDDMK
Duct mounting kit
Sensepoint XCD Mounting bracket
SPXCDMTBR
Mounting bracket (inc. bolts, nuts, brackets)
Sensepoint XCD Sunshade / Deluge Protection
SPXCDSDP
Sunshade / Deluge Protection
Ordering Codes of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDALMFX SPXCDALMRX SPXCDALMPX SPXCDALMO1 SPXCDALMHX SPXCDALMCX SPXCDALMG1 SPXCDALMNX SPXCDALMB1 SPXCDALMB2 SPXCDASMFX SPXCDASMRX SPXCDASMPX SPXCDASMO1 SPXCDASMHX SPXCDASMCX SPXCDASMG1 SPXCDASMNX SPXCDASMB1 SPXCDASMB2 SPXCDALMFXM SPXCDALMRXM SPXCDALMPXM SPXCDALMO1M SPXCDALMHXM SPXCDALMCXM SPXCDALMG1M SPXCDALMNXM SPXCDALMB1M SPXCDALMB2M SPXCDASMFXM SPXCDASMRXM SPXCDASMPXM SPXCDASMO1M SPXCDASMHXM SPXCDASMCXM SPXCDASMG1M SPXCDASMNXM SPXCDASMB1M SPXCDASMB2M SPXCDULNFX SPXCDULNRX
Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDULNPX SPXCDULNO1 SPXCDULNHX SPXCDULNCX SPXCDULNG1 SPXCDULNNX SPXCDULNB1 SPXCDULNB2 SPXCDUSNFX SPXCDUSNRX SPXCDUSNPX SPXCDUSNO1 SPXCDUSNHX SPXCDUSNCX SPXCDUSNG1 SPXCDUSNNX SPXCDUSNB1 SPXCDUSNB2 SPXCDULNFXM SPXCDULNRXM SPXCDULNPXM SPXCDULNO1M SPXCDULNHXM SPXCDULNCXM SPXCDULNG1M SPXCDULNNXM SPXCDULNB1M SPXCDULNB2M SPXCDUSNFXM SPXCDUSNRXM SPXCDUSNPXM SPXCDUSNO1M
Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDUSNHXM SPXCDUSNCXM SPXCDUSNG1M SPXCDUSNNXM SPXCDUSNB1M SPXCDUSNB2M SPXCDALMTX4 SPXCDASMTX4 SPXCDULNTX4 SPXCDUSNTX4 SPXCDALMTX4M SPXCDASMTX4M SPXCDULNTX4M SPXCDUSNTX4M SPXCDALMRFD SPXCDASMRFD SPXCDULNRFD SPXCDUSNRFD SPXCDALMRFDM SPXCDASMRFDM SPXCDULNRFDM SPXCDUSNRFDM SPXCDXSRFXSS SPXCDXSRRXSS SPXCDXSRPXSS SPXCDXSRB1SS SPXCDXSRB2SS
Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDASMTX4 SPXCDALMTX4 SPXCDUSNTX4 SPXCDULNTX4 SPXCDASMTX4M SPXCDALMTX4M SPXCDUSNTX4M SPXCDULNTX4M SPXCDMTBR SPXCDSDP SPXCDDM4 SPXCDDM4M SPXCDTM4 SPXCDAKS SPXCDHWES SPXCDEBS
Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
2106B1100 2106B1316 2106B1300 2106B1301 2106B1302 2106B1305 2106B1306 2106B1307 2106B1310 2106B1311 2106B1313 2106B1314 2106B1110 2106B2114 2106D2055 02000-A-1635 02000-A-1640 02000-A-1642 02000-A-1645 2106B1130 2106B1545 2106B1549 2106B1548 2106B1547 2106B1595 2106B1596 2110B1829 2110B2822 2110B3250 2110B2820 2110B2829 2110B2073 2110B1822 2110B0395 2110B0398 2110B2150 2110B3072 2110B3000 2110B3010 2110B3020 2110B3040 2110B3090 2110B3100 2110B3110 2110B3130 2110B3140 2110B3150 2110B3160 2110B3052 2110B3430 2110B3200 2110B3210 2110B3220 2110B3230 2110B3240 2110B3250 2110B3530 2110B3270 2110B3290 2110B3300 2110B3320 2110B3330 2110B3340 2110B3350 2110B3570 2110B3540 2110B3550 2110B3560 2110B3360 2110B3370 2110B3380 2110B3390
Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
2106B1100 2106B1316 2106B1300 2106B1301 2106B1302 2106B1305 2106B1306 2106B1307 2106B1310 2106B1311 2106B1313 2106B1314 2106B1110 2106B2114 2106D2055 02000-A-1635 02000-A-1640 02000-A-1642 02000-A-1645 2106B1130 2106B1545 2106B1549 2106B1548 2106B1547 2106B1595 2106B1596 2110B1829 2110B2822 2110B3250 2110B2820 2110B2829 2110B2073 2110B1822 2110B0395 2110B0398 2110B2150 2110B3072 2110B3000 2110B3010 2110B3020 2110B3040 2110B3090 2110B3100 2110B3110 2110B3130 2110B3140 2110B3150 2110B3160 2110B3052 2110B3430 2110B3200 2110B3210 2110B3220 2110B3230 2110B3240 2110B3250 2110B3530 2110B3270 2110B3290 2110B3300 2110B3320 2110B3330 2110B3340 2110B3350 2110B3570 2110B3540 2110B3550 2110B3560 2110B3360 2110B3370 2110B3380 2110B3390
Part Numbers of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
Instrument - ATEX/IECEx/CHINA Approval (316SS) Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDASMFX ATEX/IECEx and AP approved SP XCD Flammable CAT 0-100%LEL (20 to 100%LEL, 10%LEL) with 316SS, M20 Entry
SPXCDASMRX ATEX/IECEx and AP approved SP XCD CH4(Methane) IR 0-100%LEL (20 to 100%LEL, 10%LEL) with 316SS, M20 Entry
SPXCDASMPX ATEX/IECEx and AP approved SP XCD Propane IR 0-100%LEL (20 to 100%LEL, 10%LEL) with 316SS, M20 Entry
SPXCDASMO1 ATEX/IECEx and AP approved SP XCD Oxygen 25.0%/Vol with 316SS, M20 Entry
SPXCDASMNX ATEX/IECEx and AP approved SP XCD Nitrogen Dioxide 0-10ppm (10.0 to 50.0ppm, 5ppm) with 316SS, M20 Entry
SPXCDASMHX ATEX/IECEx and AP approved SP XCD Hydrogen Sulfide 0-50ppm (10.0 to 100.0ppm, 1ppm) with 316SS, M20 Entry
SPXCDASMCX ATEX/IECEx and AP approved SP XCD Carbon Monoxide 0-300ppm (100 to 1000ppm, 100ppm) with 316SS, M20 Entry
SPXCDASMG1 ATEX/IECEx and AP approved SP XCD Hydrogen 0-1000ppm with 316SS, M20 Entry
SPXCDASMB1 ATEX/IECEx and AP approved SP XCD Carbon Dioxide IR 0-2.00%VOL with 316SS, M20 Entry
Instrument - ATEX/IECEx/CHINA Approval (LM25) Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDALMFX ATEX/IECEx and AP approved SP XCD Flammable CAT 0-100%LEL (20 to 100%LEL, 10%LEL) with LM25, M20 Entry
SPXCDALMRX ATEX/IECEx and AP approved SP XCD CH4(Methane) IR 0-100%LEL (20 to 100%LEL, 10%LEL) with LM25, M20 Entry
SPXCDALMPX ATEX/IECEx and AP approved SP XCD Propane IR 0-100%LEL (20 to 100%LEL, 10%LEL) with LM25, M20 Entry
SPXCDALMO1 ATEX/IECEx and AP approved SP XCD Oxygen 25.0%/Vol with LM25, M20 Entry
SPXCDALMNX ATEX/IECEx and AP approved SP XCD Nitrogen Dioxide 0-10ppm (10.0 to 50.0ppm, 5ppm) with LM25, M20 Entry
SPXCDALMHX ATEX/IECEx and AP approved SP XCD Hydrogen Sulfide 0-50ppm (10.0 to 100.0ppm, 1ppm) with LM25, M20 Entry
SPXCDALMCX ATEX/IECEx and AP approved SP XCD Carbon Monoxide 0-300ppm (100 to 1000ppm, 100ppm) with LM25, M20 Entry
SPXCDALMG1 ATEX/IECEx and AP approved SP XCD Hydrogen 0-1000ppm with LM25, M20 Entry
SPXCDALMB1 ATEX/IECEx and AP approved SP XCD Carbon Dioxide IR 0-2.00%VOL with LM25, M20 Entry
Instrument - UL/CSA Approval (316SS) Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDUSNFX UL/CSA approved SP XCD Flammable CAT 0-100%LEL (20 to 100%LEL, 10%LEL) with 316SS, 3/4"NPT Entry
SPXCDUSNRX UL/CSA approved SP XCD CH4(Methane) IR 0-100%LEL (20 to 100%LEL, 10%LEL) with 316SS, 3/4"NPT Entry
SPXCDUSNPX UL/CSA approved SP XCD Propane IR 0-100%LEL (20 to 100%LEL, 10%LEL) with 316SS, 3/4"NPT Entry
SPXCDUSNO1 UL/CSA approved SP XCD Oxygen 25.0%/Vol with 316SS, 3/4"NPT Entry
SPXCDUSNHX UL/CSA approved SP XCD Hydrogen Sulfide 0-50ppm (10.0 to 100.0ppm, 1ppm) with 316SS, 3/4"NPT Entry
SPXCDUSNCX UL/CSA approved SP XCD Carbon Monoxide 0-300ppm (100 to 1000ppm, 100ppm) with 316SS, 3/4"NPT Entry
SPXCDUSNNX UL/CSA approved SP XCD Nitrogen Dioxide 0-10ppm (10.0 to 50.0ppm, 5ppm) with 316SS, 3/4"NPT Entry
SPXCDUSNG1 UL/CSA approved SP XCD Hydrogen 0-1000ppm with 316SS, 3/4"NPT Entry
SPXCDUSNB1 UL/CSA approved SP XCD Carbon Dioxide IR 0-2.00%VOL with 316SS, 3/4"NPT Entry
Instrument - UL/CSA Approval (LM25) Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDULNFX UL/CSA approved SP XCD Flammable CAT 0-100%LEL (20 to 100%LEL, 10%LEL) with LM25, 3/4"NPT Entry
SPXCDULNRX UL/CSA approved SP XCD CH4(Methane) IR 0-100%LEL (20 to 100%LEL, 10%LEL) with LM25, 3/4"NPT Entry
SPXCDULNPX UL/CSA approved SP XCD Propane IR 0-100%LEL (20 to 100%LEL, 10%LEL) with LM25, 3/4"NPT Entry
SPXCDULNO1 UL/CSA approved SP XCD Oxygen 25.0%/Vol with LM25, 3/4"NPT Entry
SPXCDULNHX UL/CSA approved SP XCD Hydrogen Sulfide 0-50ppm (10.0 to 100.0ppm, 1ppm) with LM25, 3/4"NPT Entry
SPXCDULNCX UL/CSA approved SP XCD Carbon Monoxide 0-300ppm (100 to 1000ppm, 100ppm) with LM25, 3/4"NPT Entry
SPXCDULNNX UL/CSA approved SP XCD Nitrogen Dioxide 0-10ppm (10.0 to 50.0ppm, 5ppm) with LM25, 3/4"NPT Entry
SPXCDULNG1 UL/CSA approved SP XCD Hydrogen 0-1000ppm with LM25, 3/4"NPT Entry
SPXCDULNB1 UL/CSA approved SP XCD Carbon Dioxide IR 0-2.00%VOL with LM25, 3/4"NPT Entry
Instrument - ATEX/IECEx/CHINA Approval (316SS) with ModBus Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDASMFXM ATEX/IECEx and AP approved SP XCD Flammable CAT 0-100%LEL (20 to 100%LEL, 10%LEL) with 316SS, M20 Entry, with
ModBus
SPXCDASMRXM ATEX/IECEx and AP approved SP XCD CH4(Methane) IR 0-100%LEL (20 to 100%LEL, 10%LEL) with 316SS, M20 Entry, with
ModBus
SPXCDASMPXM ATEX/IECEx and AP approved SP XCD Propane IR 0-100%LEL (20 to 100%LEL, 10%LEL) with 316SS, M20 Entry, with ModBus
SPXCDASMO1M ATEX/IECEx and AP approved SP XCD Oxygen 25.0%/Vol with 316SS, M20 Entry, with ModBus
SPXCDASMNXM ATEX/IECEx and AP approved SP XCD Nitrogen Dioxide 0-10ppm (10.0 to 50.0ppm, 5ppm) with 316SS, M20 Entry, with
ModBus
SPXCDASMHXM ATEX/IECEx and AP approved SP XCD Hydrogen Sulfide 0-50ppm (10.0 to 100.0ppm, 1ppm) with 316SS, M20 Entry, with
ModBus
SPXCDASMCXM ATEX/IECEx and AP approved SP XCD Carbon Monoxide 0-300ppm (100 to 1000ppm, 100ppm) with 316SS, M20 Entry, with
ModBus
SPXCDASMG1M ATEX/IECEx and AP approved SP XCD Hydrogen 0-1000ppm with 316SS, M20 Entry
SPXCDASMB1M ATEX/IECEx and AP approved SP XCD Carbon Dioxide IR 0-2.00%VOL with 316SS, M20 Entry, with ModBus
Instrument - ATEX/IECEx/CHINA Approval (LM25) with ModBus Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDALMFXM ATEX/IECEx and AP approved SP XCD Flammable CAT 0-100%LEL (20 to 100%LEL, 10%LEL) with LM25, M20 Entry, with
ModBus
SPXCDALMRXM ATEX/IECEx and AP approved SP XCD CH4(Methane) IR 0-100%LEL (20 to 100%LEL, 10%LEL) with LM25, M20 Entry, with
ModBus
SPXCDALMPXM ATEX/IECEx and AP approved SP XCD Propane IR 0-100%LEL (20 to 100%LEL, 10%LEL) with LM25, M20 Entry, with ModBus
SPXCDALMO1M ATEX/IECEx and AP approved SP XCD Oxygen 25.0%/Vol with LM25, M20 Entry, with ModBus
SPXCDALMNXM ATEX/IECEx and AP approved SP XCD Nitrogen Dioxide 0-10ppm (10.0 to 50.0ppm, 5ppm) with LM25, M20 Entry, with
ModBus
SPXCDALMHXM ATEX/IECEx and AP approved SP XCD Hydrogen Sulfide 0-50ppm (10.0 to 100.0ppm, 1ppm) with LM25, M20 Entry, with
ModBus
SPXCDALMCXM ATEX/IECEx and AP approved SP XCD Carbon Monoxide 0-300ppm (100 to 1000ppm, 100ppm) with LM25, M20 Entry, with
ModBus
SPXCDALMG1M ATEX/IECEx and AP approved SP XCD Hydrogen 0-1000ppm with LM25, M20 Entry, with ModBus
SPXCDALMB1M ATEX/IECEx and AP approved SP XCD Carbon Dioxide IR 0-2.00%VOL with LM25, M20 Entry, with ModBus
Instrument - UL/CSA Approval (316SS) with ModBus Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDUSNFXM UL/CSA approved SP XCD Flammable CAT 0-100%LEL (20 to 100%LEL, 10%LEL) with 316SS, 3/4"NPT Entry, with ModBus
SPXCDUSNRXM UL/CSA approved SP XCD CH4(Methane) IR 0-100%LEL (20 to 100%LEL, 10%LEL) with 316SS, 3/4"NPT Entry, with ModBus
SPXCDUSNPXM UL/CSA approved SP XCD Propane IR 0-100%LEL (20 to 100%LEL, 10%LEL) with 316SS, 3/4"NPT Entry, with ModBus
SPXCDUSNO1M UL/CSA approved SP XCD Oxygen 25.0%/Vol with 316SS, 3/4"NPT Entry, with ModBus
SPXCDUSNHXM UL/CSA approved SP XCD Hydrogen Sulfide 0-50ppm (10.0 to 100.0ppm, 1ppm) with 316SS, 3/4"NPT Entry, with ModBus
SPXCDUSNCXM UL/CSA approved SP XCD Carbon Monoxide 0-300ppm (100 to 1000ppm, 100ppm) with 316SS, 3/4"NPT Entry, with ModBus
SPXCDUSNNXM UL/CSA approved SP XCD Nitrogen Dioxide 0-10ppm (10.0 to 50.0ppm, 5ppm) with 316SS, 3/4"NPT Entry, with ModBus
SPXCDUSNG1M UL/CSA approved SP XCD Hydrogen 0-1000ppm with 316SS, 3/4"NPT Entry, with ModBus
SPXCDUSNB1M UL/CSA approved SP XCD Carbon Dioxide IR 0-2.00%VOL with 316SS, 3/4"NPT Entry, with ModBus
Instrument - UL/CSA Approval (LM25) with ModBus Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDULNFXM UL/CSA approved SP XCD Flammable CAT 0-100%LEL (20 to 100%LEL, 10%LEL) with LM25, 3/4"NPT Entry, with ModBus
SPXCDULNRXM UL/CSA approved SP XCD CH4(Methane) IR 0-100%LEL (20 to 100%LEL, 10%LEL) with LM25, 3/4"NPT Entry, with ModBus
SPXCDULNPXM UL/CSA approved SP XCD Propane IR 0-100%LEL (20 to 100%LEL, 10%LEL) with LM25, 3/4"NPT Entry, with ModBus
SPXCDULNO1M UL/CSA approved SP XCD Oxygen 25.0%/Vol with LM25, 3/4"NPT Entry, with ModBus
SPXCDULNHXM UL/CSA approved SP XCD Hydrogen Sulfide 0-50ppm (10.0 to 100.0ppm, 1ppm) with LM25, 3/4"NPT Entry, with ModBus
SPXCDULNCXM UL/CSA approved SP XCD Carbon Monoxide 0-300ppm (100 to 1000ppm, 100ppm) with LM25, 3/4"NPT Entry, with ModBus
SPXCDULNNXM UL/CSA approved SP XCD Nitrogen Dioxide 0-10ppm (10.0 to 50.0ppm, 5ppm) with LM25, 3/4"NPT Entry, with ModBus
SPXCDULNG1M UL/CSA approved SP XCD Hydrogen 0-1000ppm with LM25, 3/4"NPT Entry, with ModBus
SPXCDULNB1M UL/CSA approved SP XCD Carbon Dioxide IR 0-2.00%VOL with LM25, 3/4"NPT Entry with ModBus
Accessories of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
S3KCAL Calibration cup
SPXCDCC Collecting cone for use with lighter than air gases
SPXCDDMK Duct mounting kit
SPXCDMTBR Mounting bracket (inc. bolts, nuts, brackets)
SPXCDSDP Sunshade / Deluge Protection
00780-A-0100 Honeywell Junction Box- Bartec OTB122 With Continuity Plate 1 X 25mm - 3 X 20mm Entries - ATEX Approved
Sensepoint XCD Sensors (316 Stainless Steel) of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDXSFXSS Flammable CAT 0-100%LEL (20 to 100%LEL, 10%LEL)
SPXCDXSRXSS Methane IR 0-100%LEL (20 to 100%LEL, 10%LEL)
SPXCDXSO1SS Oxygen 25.0%/Vol only
SPXCDXSHXSS Hydrogen Sulfide 0-50ppm (10.0 to 100.0ppm, 1ppm)
SPXCDXSCXSS Carbon Monoxide 0-300ppm (100 to 1000ppm, 100ppm)
SPXCDXSNXSS Nitrogen Dioxide 0-10ppm (10.0 to 50.0ppm, 5ppm)
SPXCDXSG1SS Hydrogen 0-1000ppm only
SPXCDXSPXSS Propane IR 0-100%LEL (20 to 100%LEL, 10%LEL)
SPXCDXSB1SS Carbon Dioxide IR 0-2.00%VOL only
Sensepoint XCD Transmitter (without Sensor)
Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDALMTXO ATEX/IECEx/China approved Sensepoint XCD O2 Transmitter, LM25 with M20 Entry
SPXCDALMTXT ATEX/IECEx/China approved Sensepoint XCD Toxic Transmitter, LM25 with M20 Entry
SPXCDALMTXF ATEX/IECEx/China approved Sensepoint XCD IR and FLAM Transmitter, LM25 with M20 Entry
SPXCDASMTXO ATEX/IECEx/China approved Sensepoint XCD O2 Transmitter, 316SS with M20 Entry
SPXCDASMTXT ATEX/IECEx/China approved Sensepoint XCD Toxic Transmitter, 316SS with M20 Entry
SPXCDASMTXF ATEX/IECEx/China approved Sensepoint XCD IR and FLAM Transmitter, 316SS with M20 Entry
SPXCDALMTXOM ATEX/IECEx/China approved Sensepoint XCD O2 Transmitter, LM25 with M20 Entry and ModBus
SPXCDALMTXTM ATEX/IECEx/China approved Sensepoint XCD Toxic Transmitter with LM25, M20 Entry, with ModBus
SPXCDALMTXFM ATEX/IECEx/China approved Sensepoint XCD IR and FLAM Transmitter, LM25 with M20 Entry and ModBus
SPXCDASMTXOM ATEX/IECEx/China approved Sensepoint XCD O2 Transmitter, 316SS with M20 Entry and ModBus
SPXCDASMTXTM ATEX/IECEx/China approved Sensepoint XCD Toxic Transmitter, 316SS with M20 Entry and ModBus
SPXCDASMTXFM ATEX/IECEx/China approved Sensepoint XCD IR and FLAM Transmitter, 316SS with M20 Entry and ModBus
SPXCDULNTXO UL approved Sensepoint XCD O2 Transmitter, LM25 with 3/4"NPT Entry
SPXCDULNTXT UL approved Sensepoint XCD Toxic Transmitter, LM25 with 3/4"NPT Entry
SPXCDULNTXF UL approved Sensepoint XCD IR and FLAM Transmitter, LM25 with 3/4"NPT Entry
SPXCDUSNTXO UL approved Sensepoint XCD O2 Transmitter, 316SS with 3/4"NPT Entry
SPXCDUSNTXT UL approved Sensepoint XCD Toxic Transmitter with 316SS, 3/4"NPT Entry
SPXCDUSNTXF UL approved Sensepoint XCD IR and FLAM Transmitter, 316SS with 3/4"NPT Entry
SPXCDULNTXOM UL approved Sensepoint XCD O2 Transmitter, LM25 with 3/4"NPT Entry and ModBus
SPXCDULNTXTM UL approved Sensepoint XCD Toxic Transmitter, LM25 with 3/4"NPT Entry and ModBus
SPXCDULNTXFM UL approved Sensepoint XCD IR and FLAM Transmitter, LM25 with 3/4"NPT Entry and ModBus
SPXCDUSNTXOM UL approved Sensepoint XCD O2 Transmitter, 316SS with 3/4"NPT Entry and ModBus
SPXCDUSNTXTM UL approved Sensepoint XCD Toxic Transmitter, 316SS with 3/4"NPT Entry and ModBus
SPXCDUSNTXFM UL approved Sensepoint XCD IR and FLAM Transmitter, 316SS with 3/4"NPT Entry and ModBus
Miscellaneous Spares of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDDMF Replacement display module for Cat and IR
SPXCDDMT Replacement display module for O2 and Toxic
SPXCDDMFM Replacement display module (Cat and IR) with ModBus
SPXCDDMTM Replacement display module O2 and Toxic with ModBus
SPXCDTMF Replacement terminal module for Cat and IR
SPXCDTMO Replacement terminal module for O2
SPXCDTMT Replacement terminal module for Toxic
SPXCDMAG Magnet
SPXCDWP XCD Weather proof cap
SPXCDSRLS Sensor Retainer with locking screw
SPXCDAKS Allen key for stopper
SPXCDHWES Hex wrench for earth screw
SPXCDEBS Earth Bracket and screws
Instrument - Sensepoint XCD RFD Transmitter of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDASMRFD ATEX/IECEx and AP approved SP XCD RFD Transmitter with 316SS
SPXCDALMRFD ATEX/IECEx and AP approved SP XCD RFD Transmitter with LM25
SPXCDUSNRFD cCSAus approved SP XCD RFD Transmitter with 316SS, 3/4"NPT Entries
SPXCDULNRFD cCSAus approved SP XCD RFD Transmitter with LM25, 3/4" NPT Entries
Instrument - Sensepoint XCD RFD Remote Plug-in Sensor and Socket Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDXSRFXSS Sensepoint XCD RFD remote plug-in sensor and socket, flammable CAT 0-100%LEL (20,0 to 100.0%LEL)
SPXCDXSRRXSS Sensepoint XCD RFD remote plug-in sensor and socket, Methane IR 0-100%LEL (20,0 to 100.0%LEL)
SPXCDXSRPXSS Sensepoint XCD RFD remote plug-in sensor and socket, Propane IR 0-100%LEL (20,0 to 100.0%LEL)
SPXCDXSRB1SS Sensepoint XCD RFD remote plug-in sensor and socket, Carbon Dioxide IR 0-2.00%VOL only
Instrument - Sensepoint XCD RFD Transmitter with ModBus Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDASMRFDM ATEX/IECEx and AP approved SP XCD RFD Transmitter, 316SS, 2x M20 and 1x M25 entries, with ModBus
SPXCDALMRFDM ATEX/IECEx and AP approved SP XCD RFD Transmitter, LM25, 2x M20 and 1x M25 entries, with ModBus
SPXCDUSNRFDM cCSAus approved SP XCD RFD Transmitter with 316SS, 3/4"NPT Entries, with ModBus
SPXCDULNRFDM cCSAus approved SP XCD RFD Transmitter with LM25, 3/4" NPT Entries, with ModBus
Accessories of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDWP XCD Weather proof cap
S3KCAL Calibration cup (flow adapter) for Series 3000 and XNX EC toxic sensors
SPXCDCC Collecting cone for use with lighter than air gases
SPXCDDMK Duct mounting kit
SPXCDMTBR Mounting bracket (inc. bolts, nuts, brackets)
SPXCDSDP Sunshade / Deluge Protection
00780-A-0100 Honeywell Junction Box- Bartec OTB122 With Continuity Plate 1 X 25mm - 3 X 20mm Entries - ATEX Approved
Spares of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDXSFXSS Flammable CAT 0-100%LEL (20 to 100%LEL, 10%LEL)
SPXCDXSRXSS Methane IR 0-100%LEL (20 to 100%LEL, 10%LEL)
SPXCDXSPXSS Propane IR 0-100%LEL (20 to 100%LEL, 10%LEL)
SPXCDXSB1SS Carbon Dioxide IR 0-2.00%VOL only
SPXCDDMR XCD RFD Flam and IR Display Module
SPXCDDMRM XCD RFD Flam and IR Display Module, ModBus
SPXCDTMR XCD RFD Replacement Terminal Module
SPXCDMAG Magnet
SPXCDSRLS Sensor Retainer with locking screw
SPXCDAKS Allen key for stopper
SPXCDHWES Hex wrench for earth screw
SPXCDEBS Earth Bracket and Screws
Instrument - Sensepoint XCD RTD 4-20mA Input Transmitter (Transmitter Only) Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDASMTX4 ATEX/IECEx and AP approved SP XCD 4~20mA Input Transmitter with 316SS, M20 Entry
SPXCDALMTX4 ATEX/IECEx and AP approved SP XCD 4~20mA Input Transmitter with LM25, M20 Entry
SPXCDUSNTX4 cCSAus approved SP XCD RTD Transmitter with 316SS
SPXCDULNTX4 cCSAus approved SP XCD RTD Transmitter with LM25
Instrument - Sensepoint XCD RTD 4-20mA Input Transmitter with ModBus (Transmitter Only) Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDASMTX4M ATEX/IECEx and AP approved SP XCD 4~20mA Input Transmitter with 316SS, with ModBus
SPXCDALMTX4M ATEX/IECEx and AP approved SP XCD 4~20mA Input Transmitter with LM25, with ModBus
SPXCDUSNTX4M cCSAus approved SP XCD RTD Transmitter with 316SS, with ModBus
SPXCDULNTX4M cCSAus approved SP XCD RTD Transmitter with LM25, with ModBus
Accessories and Spares of Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
SPXCDMTBR Mounting bracket (inc. bolts, nuts, brackets)
SPXCDSDP Sunshade / Deluge Protection
SPXCDDM4 Sensepoint XCD RTD Toxic and O2 Display Module
SPXCDDM4M Sensepoint XCD RTD Toxic and O2 ModBus Display Module
SPXCDTM4 Sensepoint XCD RTD Replacement terminal module
SPXCDAKS Allen key for stopper
SPXCDHWES Hex wrench for earth screw
SPXCDEBS Earth Bracket and Screws
SPXCDMAG Magnet
Honeywell SPXCDALMRFD Sensepoint XCD RFD Remote Flammable Detectors SPXCDALMRFD Transmitters Arrived
We are specialized in intelligent instruments, including : Transmitters, Flowmeters, Analyzers,Communicators, Safety Barriers, Sensors,Gas Detectors, PLC(DCS), Multimeters, Calibrators, Communicators, Recorder, Inverters, Positioners, Valves, Soft Starters, Circuit Breakers, Contactors, Rail Switches, Power Supply, HMI, Terminal Block, Relay etc.
We mainly supply Yokogawa,Emerson, Rosemount,Fisher,Honeywell,Siemens, ABB,FLUKE, Schneider Electric, Pepperl+Fuchs,MTL, Rockwell(Allen Bradley), Hirschmann, Eaton ,Moeller,FUJI,Omron, Yaskawa,Norgren,CHINT,Hach,Weidmuller,Phoenix, SMC,Testo, ASCO,Parker,Mitsubishi, Festo,GE, CISCO,Auma,IFM,GM,Turck,MOXA, Foxboro, Krohne, Swagelok, LS, Advantech, Dwyer,Endress Hauser, Bently Nevada etc.
Contact:
HONGKONG XIEYUAN TECH CO., LIMITED
Email:becky@hkxytech.com Web:www.hkxytech.com
Mobile:+86-15972186287(Whatsapp & Wechat)
